Specification
Frame:
| Model | P1 Frame |
| Type | Trail Bike |
| Material | Full Carbon Toray T1100 |
| Size | XS/S/M/L/XL |
| Headset | 1-1/8”, 1-1/2” Internal |
| Bottom | BSA73 Boost |
| Shock Size | 200*51mm, eye to eye: 22.2*8mm—-340 |
| Rear Travel | 130mm |
| Dropout | 12*148mm |
| Seat Post | 31.6mm |
| Weight (frame) | XS-2350g+-40g; S-2380g+-40g; M-2430g+-40g; L-2470g+-40g; XL-2490g+-40g |
| Thru Axle | 12*148mm, Boost*1.5mm |
| Max tire sizes | 27.5*2.8″ or 29*2.3″, if using XD12S EAGLE groupset, then 27.5*2.5″ or 29*2.3″ |
Wheelset:
| Model | AM29540 Carbon Mountain Bike Clincher Tubeless Ready Material: Full Carbon Toray T1100 |
| Rims | AM2940, 32/32H |
| Width | inner: 30mm, outer: 35mm |
| Depth | 25mm |
| Finish | UD Matt |
| Hubs | Novatec D791SB/D792SB |
| Spokes | Sapim Basic Leader Round Spokes |
Groupset: SHIMANO6100
| Speed | 12 speed |
| Chainset | Shimano Deore FCM6100 32T 170mm |
| Rear Mech | Shimano Deore RDM6100SGS |
| Shifter | Shimano Deore SLM6100R |
| Cassette | Shimano Deore 10-51 |
| Chain | Shimano Deore CNM6100126Q |
| Left Brake | Shimano Deore M6100LR |
| Right Brake | Shimano Deore M6100RF |
Other Components:
| Fork | Rockshox Yari 27.5 plus, Black, Travel 130mm, 15*110mm axle |
| Maxxis Tire | Maxxis 29*2.3’’ Minion |
| Seat Post | EXP Adjust Seat Post Manic 150mm |
| Saddle | Carbon SD01 |
| Handlebar | HB011 760mm Full Carbon |
| Bottle Cage | Full Carbon BC02 |
| Stem | ST03 Alloy |
| Pedal | Alloy |
| Size | L, M, S, XL, XS |
|---|
Frequently Asked Questions
1.Do you provide OEM manufacturing services for private brands?
Yes. Sunremo has over 20 years of experience in OEM manufacturing, delivering premium-quality customized bicycle frames for global brands. From material selection to final quality inspection, every step follows strict manufacturing standards to ensure consistency, reliability, and long-term performance.
2.Can you develop a custom frame design exclusively for our brand?
Absolutely. We offer both OEM and ODM solutions. Whether you already have drawings or need full product development from concept, our engineering team supports geometry design, layup optimization, prototyping, testing, and mass production — ensuring your product stands out in both performance and branding.
3.Do you work with small or emerging brands?
Yes. We partner with brands of all sizes, from startups to established international companies. Our flexible production system allows scalable order quantities while maintaining the same quality standards and technical support.
4.What is your minimum order quantity (MOQ)?
MOQ depends on the model and customization level.
Standard models: The standard MOQ is 100 pieces
Full custom ODM projects: discussed based on tooling and development scope
Please contact us for an accurate quotation.
5.Can you provide samples or prototypes before mass production?
Yes. We strongly recommend sample validation before bulk production.
Prototype lead time is usually 20–45 days, depending on complexity and testing requirements.
6.What quality standards and certifications do you follow?
Our frames are manufactured under strict quality management systems.
Products can be tested and certified according to ISO, EN, and UCI standards upon request, ensuring compliance with international safety and performance requirements.
7.What warranty do you offer?
Sunremo provides a 2–5 year structural warranty depending on the frame model and application. Detailed warranty terms are supplied with each project.
8.What payment methods do you accept?
We accept secure and flexible payment methods including T/T, L/C, D/P, D/A, PayPal, and bank transfer.
9.How long is production and delivery time?
Production time depends on order volume and customization level:
10.Why choose Sunremo as your manufacturing partner?
✅ Direct factory with stable production capacity
✅ Advanced carbon fiber manufacturing expertise
✅ Strict QC and traceability system
✅ Flexible OEM/ODM cooperation model
✅ Competitive pricing with premium quality
✅ Professional international communication support
